介面
|
WAN/LAN可切換埠 |
2x 10G/2.5G/1G SFP+ 光纖接口 4x 1G/100M/10M Ethernet, RJ-45 |
LAN埠 |
4x 1G/100M/10M Ethernet, RJ-45 |
USB孔 |
2x USB 3.0可當USB磁碟 |
Console埠 |
1x RJ-45 |
按鈕 |
1x 重置鍵 |
效能
|
NAT最快速度 |
9.4 Gbps |
NAT連線數 |
1,000,000 |
同時最多VPN連線數 |
2 |
同時最多OpenVPN + SSL VPN連線數 |
2 |
Internet Connection
|
IPv4 |
PPPoE, DHCP, Static IP |
IPv6 |
PPP, DHCPv6, Static IPv6, TSPC, AICCU, 6rd, 6in4 Static Tunnel |
802.1p/q Multi-VLAN Tagging |
有
|
Multi-VLAN/PVC |
有 |
Load Balancing |
IP-based, Session-based |
WAN Active on Demand |
Link Failure, Traffic Threshold |
Connection Detection |
ARP, Ping, Strict ARP |
WAN Data Budget |
有 |
Dynamic DNS |
有 |
DrayDDNS |
有 |
LAN Management
|
VLAN |
802.1q Tag-based, Port-based |
Max. Number of VLAN |
100 |
Number of LAN Subnet |
100 |
DHCP Server |
Multiple IP Subnet, Custom DHCP Options, Bind-IP-to-MAC |
LAN IP Alias |
有 |
IP Pool Count |
Up to 4K per LAN Subnet |
PPPoE Server |
有 |
Port Mirroring |
有 |
Local DNS Server |
有 |
Conditional DNS Forwarding |
有 |
Hotspot Web Portal |
有 |
Hotspot Authentication |
Click-Through, Social Login, SMS PIN, RADIUS, External Portal Server |
Networking
|
Routing |
IPv4 Static Routing, IPv6 Static Routing, Inter-VLAN Routing, RIP v1/v2 |
Policy-based Routing |
Protocol, IP Address, Port, Domain, Country |
High Availability |
Active-Standby, Hot-Standby |
DNS Security (DNSSEC) |
|
IGMP |
IGMP v2/v3, IGMP Proxy, IGMP Snooping & Fast Leave |
Local RADIUS server |
|
SMB File Sharing |
(Requires external storage) |
VPN (for management purpose)
|
LAN-to-LAN |
有 |
Teleworker-to-LAN |
有 |
Protocols |
PPTP, L2TP, IPsec, L2TP over IPsec, SSL, GRE, IKEv2, IPsec-XAuth, OpenVPN(Host to LAN) |
User Authentication |
Local, RADIUS, LDAP, TACACS+, mOTP |
IKE Authentication |
Pre-Shared Key, X.509, XAuth, EAP |
IPsec Authentication |
SHA-1, SHA-256, MD5 |
Encryption |
MPPE, DES, 3DES, AES |
Single-Armed VPN |
有 |
NAT-Traversal (NAT-T) |
有 |
DrayTek VPN Matcher |
有 |
Firewall & Content Filtering
|
NAT |
Port Redirection, Open Ports, Port Triggering, DMZ Host |
ALG (Application Layer Gateway) |
SIP, RTSP, FTP, H.323 |
VPN Pass-Through |
PPTP, L2TP, IPsec |
IP-based Firewall Policy |
有 |
Content Filtering |
Application, URL, DNS Keyword, Web Features, Web Category* (*: subscription required) |
DoS Attack Defense |
有 |
Spoofing Defense |
有 |
Bandwidth Management
|
IP-based Bandwidth Limit |
有 |
IP-based Session Limit |
有 |
QoS (Quality of Service) |
TOS, DSCP, 802.1p, IP Address, Service Type |
VoIP Prioritization |
有 |
Management
|
Local Service |
HTTP, HTTPS, Telnet, SSH v2, FTP, TR-069 |
Config File Export & Import |
有 |
Firmware Upgrade |
TFTP, HTTP, TR-069 |
2-Level Administration Privilege |
有 |
Access Control |
Access List, Brute Force Protection |
Syslog |
有 |
Notification Alert |
SMS, E-mail |
SNMP |
v1, v2c, v3 |
Central AP Management |
50 VigorAPs |
Central Switch Management |
30 VigorSwitches |
物理特性
|
可安裝於19吋機架 |
內附機架組 |
尺寸 |
443 mm x 285 mm x 45 mm |
重量 |
3.32 kg |
電源 |
AC 110~220V @ 1A |
最大電耗 |
32 瓦 |
操作溫度範圍 |
0 至 45°C |
儲存溫度範圍 |
-10 至 55°C |
操作濕度範圍 |
10 至 90% (non-condensing) |
安規認證 |
|
